Items Specification Main Steel Frame Column Q235, Q355 Welded H Section Steel Beam Q235, Q355 Welded H Section Steel Secondary Frame Purlin Q235 C and Z purlin Knee brace Q235 Angle Steel Tie Rod Q235 Circular Steel Pipe Brace Q235 Round Bar Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe Maintenance system Roof Panel EPS Sandwich Panel /Glass Fiber Sandwich Panel /PU/Single color sheet Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet Wall Panel Sandwich Panel / Corrugated Steel Sheet Accessories Window Aluminium Alloy Window / PVC Window / Sandwich Panel Window Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door Downspout PVC Live load on Roof In 120kg/Sqm (Color steel panel surrounded) Wind Resistance Grade 12 Grades Earthquake-resistance 8 Grades Structure Usage Up to 50 years Temperature Suitable temperature.-50ºC~+50ºC Certification CE, SGS, ISO9001:2008, ISO14001:2004 Finishing Options Vast array of colors and textures available Paint Options Alkyd painting, two primary painting, two finish painting (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.   To learn more about how KXD STEEL can support your next big project, contact us today. Andy Yu WhatsApp us at +86 138 5323 3236 Email us at : kxdandy@chinasteelstructure.cn

Prefabricated steel structure building for garment factory. Project Name : Portal Frame Steel Structure. Project Area: 100,000 sqm Construction Site: Ethiopia Project details : It includes 2 garment workshops ,office building ,staff dormitory and light steel villa. 1. Primary steel structure: welded H section steel with primer & facing anti-rusting painting and fire proof coatings. 2. Second farme : Galvanization purlin, roof and wall support are formed as secondary frame structure . 3. Roof: color-coated corrugated steel sheet + EVA +steel mesh. 4. Wall : Exterior and interior color-coated corrugated steel sheet with fiber glass wool insulation and glass curtain wall as decoration.   To learn more about how KXD STEEL can support your next big project, contact us today. Andy Yu WhatsApp us at +86 138 5323 3236 Email us at : kxdandy@chinasteelstructure.cn

Location: Peru Project Name: Logistics Distribution Warehouse Products: Steel columns, steel beams, purlins, roof and wall panels, etc To learn more about how KXD STEEL can support your next big project, contact us today. Andy Yu WhatsApp us at +86 138 5323 3236 Email us at : kxdandy@chinasteelstructure.cn

Project location: Romania Product:  steel structure columns and beams，etc Surface treatment: gray paint To learn more about how KXD STEEL can support your next big project, contact us today. Andy Yu WhatsApp us at +86 138 5323 3236 Email us at : kxdandy@chinasteelstructure.cn

Specifications 1)Size(m): Width * Length * Height; 2)Type: Single slope, double slope, Multi-slope; Single span, double-span, Multi-span; Single floor, double-floor, Multi-floor; 3) Base: steel foundation bolts 4) Steel frame: Material Q345(S355JR)(Gr50)or Q235(S235JR) steel; Straight cross-section or Variable cross-section; steel welded H section painted or galvanized. 5) Bracing: X-type or V-type or other type bracing made from angle, round bar, etc ; 6) Wall & Roof Purlin: C section channel or Z section channel ,Size from C80~C300; Z100~Z300; 7) Roof & wall cladding Single color corrugated steel sheet 0.326~0.7mm thickness; Sandwich panel with EPS, ROCK WOOL,GLASS WOOL, PU etc insulation, thickness around 50mm 75mm 100mm 120mm 150mm 200mm; recommend coating PVDF SMP HDP PE 8)Window: UPVC/PVC or Aluminum Alloy window frame with glass. 9)Door: Exterior door:Sliding or Roller shutter door. Internal door:50mm thickness EPS sandwich panel with an aluminum alloy door frame 10) Gutter material: Color steel sheet or galvanized steel or stainless steel; 11)Rainspout: PVC pipe 12)Connection high strength bolts ,intensive bolt,self-drilling screws. 13)Accessories: Skylight panel, Ventilation, Fasteners etc 14)Surface process: Shot blasting Sa2.5;Two layers of Anti-rust Painting or galvanized 15) Packing: Main steel frame without packing load in 40' GP, roof and wall panel load in 40' HQ   To learn more about how KXD STEEL can support your next big project, contact us today. Andy Yu WhatsApp us at +86 138 5323 3236 Email us at : kxdandy@chinasteelstructure.cn
